Compact Multi Channel Transmitter and Receiver (4 Channels)CDP-TX-07M/MP, CDP-RX-07M/MP

CDP-TX-07M/MP and CDP-RX-07M/MP are low power narrow band FSK transmitter and receiver modules, designed for industrial applications operating in 434 MHz. The modules contain most of the components necessary for radio communication in compact cases. The operating RF channel can be selected from 4 preset frequency channels. The receiver is double-superheterodyne and equipped with a SAW filter, ensuring high sensitivity and very good selectivity for stable and long range communication.

The CDP-TX-07M, CDP-RX-07M is compatible with CDP-TX-05M-R and CDP-RX-05M-R

CDP-TX-07MP, CDP-RX-07MP has connection pins S1 and S2 allowing frequency setting to be performed externally.



Model name TX / RX Ch setting
CDP-TX-07M Transmitter Jumper
CDP-RX-07M Receiver Jumper
CDP-TX-07MP Transmitter Pin connectors S1 and S2
CDP-RX-07MP Receiver Pin connectors S1 and S2

Features

  • 10 mW RF output
  • Wide operating temperature (-20 to + 65 degree C)
  • 4 preset channels* containing 4 frequencies in the 434 MHz band
  • PLL controlled VCO, data rate 100 to 4,800 bps FSK
  • Compact size
    Transmitter 22 x 12 x 4.5 mm
    Receiver 36 x 26 x 8 mm
  • Receiver category 1
  • RED compliant (EN 300 220)
  • RoHS compliance

* For the CDP-TX-07MP and CDP-RX-07MP, the user can reprogram each channel with a frequency selected from 67 frequencies in the 434 MHz band using a dedicated setting program.

Applications

  • Remote control systems
  • Security and alarm systems
  • Telemetry and monitoring systems
  • Tracking systems

Other products related to this product

CDP-TX-05M-R, CDP-RX-05M-R

Compact Multi Channel Transmitter and Receiver (4 Channels)

CDP-TX-02E/EP, CDP-RX-02E/EP

Multi Channel Radio Transmitter and Receiver (32 Channels)

CDP-TX-02F, CDP-RX-02F

Multi Channel Radio Transmitter and Receiver (128 Channels)

Specifications

Common

Parameter Specification Remarks
Applicable standard RED compliant
(EN 300 220)
Communication method One way
Emission type F1D FM narrow
Oscillation system Crystal based PLL oscillation
Number of channels 4 channels *
Frequency 434.075 MHz
433.920 MHz
434.600 MHz
434.700 MHz
RF bit rate 100 to 4,800 bps
Pulse width Min. 208 us / Max. 20 ms
Operating temp. range -20 to +65 degree C

* Each of the 4 preset channels are reprogrammable using values chosen from a frequency table containing 67 values that consists of 433.920 MHz and values from 434.075 to 434.700 MHz with 25 kHz spacing. To reprogram the preset channels, a dedicated setting program is provided.

Transmitter Part

Parameter Specification Remarks
Transmitter type Crystal based PLL oscillation
RF output power 10 mW
Data input Digital L=GND, H=Vcc
Deviation +/-3.0 KHz PN9 4,800 bps
Spurious emission < -54 dBm (< 862 MHz)
< -36 dBm (862 to 1000 MHz)
< -30 dBm (> 1000 MHz)
Adjacent channel power < -37 dBm
Supply voltage 2.2 to 5.5 V DC
Supply current 20 mA typ.
I/O terminals RF out, Gnd, Vcc, Data In, (JP1 / JP2) CDP-TX-07M
RF out, Gnd, Vcc, Data In, Mode, S1, S2 CDP-TX-07MP
Dimension 22 x 12 x 4.5 mm
Weight 2 g

Receiver Part

Parameter Specification Remarks
Oscillation system Crystal based PLL oscillation
Receiver category 1
Receiver sensitivity -120 dBm
-115 dBm
12dB SINAD
BER 0.1%
Adjacent channel selectivity 45 dB
Spurious radiations < -60 dBm
Data output Digital L=GND, H=Vcc
Supply Voltage 3.0 to 14 V DC
Supply current 23 mA typ. 3V
I/O terminals Ant, Gnd, Vcc, Data out, AF out, RSSI out, Power Control, (JP1 / JP2) CDP-RX-07M
Ant, Gnd, Vcc, Data out, AF out, RSSI out, Power Control, Mode, S1,S2 CDP-RX-07MP
Dimensions 36 x 26 x 8 mm
Weight 13 g

External View

CDP-TX-07M

CDP-RX-07M

CDP-TX-07MP

CDP-RX-07MP

Application Notes

How to reprogram the preset frequencies of the CDP-TX-07MP/CDP-RX-07MP
Setting program
How to reprogram the preset frequencies - Demonstration video

TB-CDP-TX-04S , TB-CDP-RX-03AS

Operation Guide

Version 2.0

Evaluation Tools: TB-CDP-TX-04S, TB-CDP-RX-03AS

The test board will save you time and effort for evaluating CDP-TX-07M and CDP-RX-07M modules. Communication range can be tested easily by checking the LEDs on the decoder board TB-CDP-RX-03AS.

TB-CDP-TX-04S and TB-CDP-RX-03AS do not include modules CDP-TX-07M and CDP-RX-07M. Please make sure to order them if needed. The boards are common for CDP-TX-05M-R / RX-05M-R models. Also the testboard cannot be used for CDP-TX-07MP and CDP-RX-07MP.

Features

  • 4-push buttons and output LEDs
  • 8-bit ID dip switch
